TORNADOFLAMERM SF-180 Moving Head Flame Machine

Specification

• IP55 (waterproof design)
• Flame effects up to 8 - 10 metres
• Controlled by DMX to display 89 flame combinations
• 88 pre-set flame sequences when controlled by PYROSIMCON CT-05

• Input Voltage & Rate: 240 V 50 HZ
• Power Consumption: 320W
• Power Input Connector: SEETRONIC

• Power Output Connector: SEETRONIC
• DMX Signal Interface: 3 PIN / 5 PIN double DMX interface

Interface type

• Signal Interface: 3 PIN / 5 PIN double DMX interface
• Signal Interface: 9V - 60 V fireworks ignition signal interface

Hopper

• Fuel Bottle Capacity: 10 Litre

Control

• Control Protocol: DMX512

• DMX Channels: 2CH and 6CH
• Control Mode: Standard DMX signal control

• Effect Angles: Vertical

• SMPTE: Touch Screen console support

Accessory

• Power Plug: SEETRONIC (1.6 Metre)
• Remote Controller: (Optional)
• DMX Cable: 3M
• Power Cable: 3M
• Safety Loop
• Safety Rope

Oil Consumption

• Firing Head L (Standard Configuration): 30mls
• Firing Head M (Standard Configuration): 60mls

Ignition

• Ignition Mode: High voltage electronic ignition

Weight

• Net Weight ( No Fuel): 32Kg
• Gross Weight: 42Kg

• Machine Dimension: 590 x 360 x 370 mm
• Packing Dimension: 840 x 420 x 540 mm

Fuel Oil

• Kind: Isopropanol, Isoparaffin G, H, L, M, and Bioethanol

Manual

• User Manual for Tornado Flamer SF-180

Roadcase: OPTIONAL

• TORNADOFMCASE - Case for Tornado Flame Moving Head. Holds 1 Unit.

Important: When using flame machines, a CO2 fire extinguisher and fire blanket must be readily available.

For more information, please visit the manufacturer's website.
