I FLAMER SF-90 Flame Machine Compact

Specification

• IP55 (Waterproof Design)
• Direct Shooting of Liquid Fuel up to 8-10 metres.

AC Power

• Input Voltage & Rate: 240 V 50 HZ
• Power Consumption: 300W
• Power Input Connector: SEETRONIC

• Power Output Connector: SEETRONIC
• DMX Signal Interface: 5 PIN

Interface type

• Signal Interface: Double DMX Interface
• Signal Interface: 9V - 60 V fireworks ignition signal interface

Hopper

• Fuel Bottle Capacity: 5 Litre

Control

• Control Protocol: DMX512

• DMX Channels: 2CH and 6CH
• Control Mode: Standard DMX signal control

• Effect Angles: Vertical

• SMPTE: Touch Screen console support

Accessory

• Power Plug: SEETRONIC (1.6 Metre)
• Remote Controller: (Optional)
• DMX Cable: 3M
• Power Cable: 3M
• Safety Loop

Oil Consumption

• Firing Head L (Standard Configuration): 30mls
• Firing Head M (Standard Configuration): 60mls

Ignition

• Ignition Mode: High voltage electronic ignition

Weight

• Net Weight ( No Fuel): 14Kg
• Gross Weight: 22Kg

Dimensions

• Machine Dimension: 330 x 260 x 345 mm
• Packing Dimension: 730 x 587 x 725 mm

Fuel Oil

• Kind: Isopropanol, Isoparaffin G, H, L, M, and Bioethanol

Manual

• User Manual for I Flamer SF-90

Roadcase: Optional

• IFLAMERCASE - Case for IFlamer SF-90. Fits 2 Units.

Important: When using flame machines, a CO2 fire extinguisher and fire blanket must be readily available.

For more information, please visit the manufacturer's website.
