Wharfedale Pro Delta-AX18B Active Subwoofer

Regular price
  • 18″ active subwoofer
  • Low pass filter control
  • Hi Pass link outputs
  • 38 Hz – 200 Hz Frequency response
  • 180° phase switch
  • 4″ LF voice coil
  • 1000 watts Continuous
  • 2000 watts Peak
  • 132 dB Max SPL @ 1m


    All Delta-AX models use premium Baltic birch plywood construction.

    Not only does this create a solid and durable cabinet, but it also contributes to the overall sound and character.

    Delta-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a Delta-AX will always look as good as the day you unboxed it.


    Delta-AX features a routed Wharfedale Pro logo.

    This fresh design helps to distinguish between the original Delta-A models and the updated Delta-AX models.

    It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.



    Model Name DELTA-AX18B
    System Type Active 18” Subwoofer
    Frequency Response (+/-3 dB) 38 Hz – 200 Hz
    Frequency Range (-10 dB)
    Calculated Maximum SPL @1 m 132 dB
    Low Frequency Transducer –
    Size (mm / inches)
    470 mm / 18″
    Coil Size (mm / inches) 101.6 mm / 4″
    Impedance 8 Ω
    Low-Frequency Power Amplifier RMS 1000 w (Class D)
    High-Frequency Power Amplifier RMS NA
    Amplifier Protection Yes
    Power On Protection Power switch on/off mute
    Thermal Protection Amplifier Shut Down. Auto Reset
    Low Line Voltage Shut Down 80% Nominal Line Voltage
    Driver Protection Yes
    DC and Short Protection Yes
    Clip Limiter Turns on Approx @ 1000 w Output
    Limiter Indicator Red LED
    Power Indicator Green LED
    Input A – type Balanced
    Input Sensitivity Line:0 dBu
    Maximum Input Level 22 dBu
    Input Connector TRS jack and Female XLR
    Input Impedance Balanced:20 KΩ Unbalanced:10 KΩ
    Line Output Connector Male XLR Connector
    Impedance Balanced Balanced: 200 Ω Unbalanced:100 Ω
    Loop Gain 0 dB
    AC Power details – Power Supply High Efficiency SMPS
    AC Power Options AC100-120 V~ / 220-240 V~,50/60 Hz
    Power On Indicator Green LED
    Hardware – Rigging
    Enclosure Material and finish 15 mm Plywood
    Colour Options Black Rhino Paint
    Grille Material & Finish
    Unpacked dimensions – Height 539 mm / 21.22″
    Width (Front) 539 mm / 21.22″
    Width (Back) 539 mm / 21.22″
    Depth 650 mm / 25.59″
    Packed Dimensions – Height 624 mm / 24.57″
    Width (Front) 722 mm / 28.43″
    Width (Back) 722 mm / 28.43″
    Depth 611 mm / 24.06″
    Net Weight (kg / lbs) 38.4 kg / 84.48 lbs
    Gross Weight (kg / lbs) 44.3 kg / 97.46 lbs


    Download user manual
