Wharfedale Pro
Wharfedale Pro DELTA-AX12 Active Speaker
Wharfedale Pro DELTA-AX12 Active Speaker
Regular price
$849.00
Regular price
Sale price
$849.00
Unit price
/
per
DELTA AX
Active plywood loudspeakers.
- Class D amplified active loudspeakers
- Custom Wharfedale Pro transducers
- Premium Baltic Birch plywood construction
- 2-way models feature internal Qubit DSP
- Subwoofers with Low Pass filter control
- 4-way rubberised handles
- Large voice coils
- Impressive SPL figures
- For install or on the road
DELTA-AX12
- 12″ two-way bi-amplified active loudspeaker
- 750 watts Continuous power
- 1500 watts Peak power
- 90° x 45° dispersion
- 2″ HF Compression driver
- 3″ LF voice coil
- Advanced Internal QuBit DSP
- 130 dB Max SPL @ 1 meter
BIRCH PLYWOOD
All Delta-AX models use premium Baltic birch plywood construction.
Not only does this create a solid and durable cabinet, but it also contributes to the overall sound and character.
Delta-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a Delta-AX will always look as good as the day you unboxed it.
ROUTED LOGO
Delta-AX features a routed Wharfedale Pro logo.
This fresh design helps to distinguish between the original Delta-A models and the updated Delta-AX models.
It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.
SPECIFICATIONS:
| Model Name | DELTA-AX12 |
|---|---|
| System Type | Active 12” 2-way Bi-Amplified |
| Frequency Response (+/-3 dB) | 60 Hz – 20 KHz |
| Frequency Range (-10 dB) | 55 Hz – 20 KHz |
| Calculated Maximum SPL @1 m | 130 dB |
| Low Frequency Transducer – Size (mm / inches) |
332 mm / 12″ |
| Coil Size (mm / inches) | 75 mm / 3″ |
| Impedance | 4 Ω |
| High Frequency Transducer – Type | Compression Driver |
| Coil Size (mm / inches) | 51.2 mm / 2″ |
| Exit Size (mm / inches) | 35.6 mm / 1.4″ |
| Diaphragm Material | Titanium |
| Impedance | 8 Ω |
| Nominal Coverage (H x V) | 90° x 45° |
| Amplifiers | |
| Low-Frequency Power Amplifier RMS | 600 w (Class D) |
| High-Frequency Power Amplifier RMS | 100 w (Class D) |
| Amplifier Protection | Yes |
| Power On Protection | Power switch on/off mute |
| Thermal Protection | Amplifier Shut Down. Auto Reset |
| Low Line Voltage Shut Down | 80% Nominal Line Voltage |
| Driver Protection | Independent LF and HF Limiters |
| DC and Short Protection | Yes |
| Clip Limiter | Turns on Approx @ 650 w Output |
| Limiter Indicator | Red LED |
| Power Indicator | Green LED |
| Connectors | |
| Input A – type | Switchable Balanced Mic or Line Level Input |
| Input Sensitivity | Mic:-40 dBu Line:0 dBu |
| Maximum Input Level | 22 dBu |
| Input Connector | XLR 1/4” Combo jack / 2 x RCA |
| Input Impedance | Balanced:20 KΩ Unbalanced:10 KΩ |
| Line Output Connector | Switchable LOOP/MIX Balanced Male XLR Connector |
| Impedance Balanced | Balanced: 200 Ω Unbalanced:100 Ω |
| Loop Gain | 0 dB |
| AC Power details – Power Supply | High Efficiency SMPS |
| AC Power Options | AC100-120 V~ / 220-240 V~,50/60 Hz |
| Power On Indicator | Green LED |
| Hardware – Rigging | M10 x 6 |
| Enclosure Material and finish | 15 mm Plywood |
| Colour Options | Black Rhino Paint |
| Grille Material & Finish | 1.2 Steel |
| Unpacked dimensions – Height | 640 mm / 25.2″ |
| Width (Front) | 390 mm / 15.35″ |
| Width (Back) | 241.2 mm / 9.5″ |
| Depth | 373 mm / 14.69″ |
| Packed Dimensions – Height | 745 mm / 29.3” |
| Width (Front) | 566 mm / 22.3” |
| Width (Back) | 328 mm / 12.9” |
| Depth | 464 mm / 18.3” |
| Net Weight (kg / lbs) | 27.9 kg / 61.2 lbs |
| Gross Weight (kg / lbs) | 32.5 kg / 71.5 lbs |
